Description:

The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or color LSZH sheath.

Features:

· Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
          transmission property.
        · Two parallel FRP strength members ensure good performance of crush resistance to protect the
          fiber.
        · Single steel wire or massagers as the additional strength member ensures good performance of tensile strength.
        · Simple structure, light weight and high practicability.
        · Novel flute design, easily strip and splice, simplify the installation and maintenance.
        · Low smoke, zero halogen and flame retardant sheath.

Datasheet:

·Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm	≤1480nm

·Technical Parameters

ber Count	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static /Dynamic mm
1	(2.0±0.2)×(5.0±0.2)	20	60/120	300/1000	15/30
2	(2.0±0.2)×(5.0±0.2)	20	60/120	300/1000	15/30
1	(2.0±0.2)×(5.6±0.2)	21	60/120	300/1000	15/30
4	(2.0±0.2)×(5.6±0.2)	22	60/120	300/1000	15/30
